SINOTRUK HOMAN 4X4 ALL WHEEL DRIVE fuel tank trucks are built in-house, from raw material to finished product. We offers an extensive line of on-road fuel trucks ranging from 5,000 to 10,000 liters tanks with a wide selection of available options. By engaging all wheels, trucks offer improved cornering stability and reduced understeer or oversteer, enhancing overall handling characteristics. This can lead to a more confident driving experience, especially at higher speeds or during sudden maneuvers.
Specification
SINOTRUK HOMAN 4X4 FUEL TANK TRUCK | |
Model | ZZ1048D3223C1 |
Cabin | 1760mm, single sleeper, with air conditioner |
Engine | YN4102QBZL, 116HP, Euro II Emission standard Option: YC4E140-33(140HP), YC4E160-33(160HP) |
Transmission | LS145H, manual, 5 F & 1 R |
Front axle | 2700kg loading capacity |
Rear axle | 7200kg loading capacity |
Steering | Bosch brand, with Hydraulic assistance |
Tire | 8.25R16, 7 pcs (including one spare tire) Option: 7.00R16,7.50R16 |
Fuel tank | 120L Option: 80L, 100L,220L |
Tank Body | 5000 liters Option: 3000L, 6000L, 8000L, 10000L |
Overall dimension | 7500*2550*3300 mm |
Color | White, Red, Blue ,Yellow, Gray |
Product Features
1. All fuel tank trucks are equipped with SINOTRUK's exclusive suspension and frame, with high quality.
2. Classic engine: 116hp, 140hp and 160hp; with Euro ll, Ill, IV, V, VI emission standard;
4: Gearbox/Transmission: Chinese brand, manual operation (MT), 5 forwards and 1 reverses.
5. Steering: Right Hand Drive, Left Hand Drive.
6. Primary functions: fuel transporting and vehicle refueling.
7. Tank body: Customized according to different purposes, like tank material(corrosion-resistant aluminum or stainless steel), tank volume(5-10m³), tank shape, compartment number, etc. And we have refueling gun, flow meter for option.
8. Seperate compartment: carry various types of fuels, including specialized fuels for industrial or agricultural equipment.
9. Tyres: Tube or tubeless is optional. Mining purpose tyres can be equipped.
10. Color: red, yellow, white is normal color, many other colors for optional.
11. More option: Fuel dispenser, Reel refueling gun, tool box, subsea valve, internal paint.
12.Better Acceleration: With power being distributed to all four wheels, ALL WHEEL DRIVE fuel tank trucks generally accelerate faster from a standstill, as there is less chance of wheelspin wasting power. This can be beneficial in both everyday driving and performance scenarios.
