SINOTRUK HOWO-7 8X4 fresh milk transportation truck is a specialized vehicle designed to transport fresh milk from dairy farms to processing factory. Equipped with food-grade stainless steel tank, a thermal insulation layer, advanced cleaning systems. The tank volume range from 25,000 to 30,000 liters. Tank volume and compartment number can be customized according to different requirements. It is an essential part of the dairy supply chain and widely used in Africa, Southeast Asia, South America, and Middle East.
Specification
SINOTRUK HOWO-7 8X4 Fresh Milk Transportation Truck | |
Model | ZZ1317N4667B1 |
Cabin | HW76, long cabin, single sleeper, with air conditioner |
Engine | WP10.380E22, 380HP, Euro II Emission standard Option: WP10.340E22 (340HP), WP12.400E201(400HP), WP12.430E201(430HP) |
Transmission | HW19710, manual, 10 F & 2 R |
Front axle | 2*9500kg loading capacity |
Rear axle | 2x16000kg loading capacity |
Steering | Bosch brand, with Hydraulic assistance |
Tire | 315/80R22.5, 13 pcs (including one spare tire) Option:12.00R20, 12.00R24, 13R22.5 |
Fuel tank | 400L |
Milk Tank | 25000L-30000L Compartment: customized |
Overall dimension | 10500*2550*3550 mm |
Color | White, Red, Blue ,Yellow, Gray |
Product Features
1. Temperature Control: No more than 1℃ in 24 hours(Temperature difference 30℃). Maintain a consistent temperature to ensure the milk remains fresh and safe during transit.
2. Sanitary Design: Made by food-grade stainless steel, which is easy to clean and resistant to corrosion, ensuring optimal hygiene and preventing contamination.
3. Insulation: The tanks are surrounded by a layer of thermal insulation to protect the milk from external temperature fluctuations, preserving its quality and extending its shelf life.
4. Cleaning Systems: Equipped with Clean-In-Place (CIP) systems, allowing for automated and thorough cleaning of the tanks without the need for manual intervention, ensuring high standards of cleanliness.
5. Specialized Handling: Designed to handle the unique properties of fresh milk, these trucks feature specialized pumping and agitation systems to keep the milk in good condition during transportation.
6. All fresh milk transportation trucks are equipped with high tensile steel leaf springs suspension and reinforced double-layer chassis.
7. Plenty of options are available, including driver's air seat ensuring driver's comfortable driving experience, engine oil pan and intercooler protection plate, top mounted alarming beams (single and dual), engine exhaust valve brake (EVB), oil bath air inlet system good for dusty working condition to protect engine from inhale impure air, reverse buzzer, wind deflector to reduce wind resistance.
8. Classic engine: 300hp, 340hp for option; with Euro ll, Ill, IV, V, VI emission standard;
9: Gearbox/Transmission: Sinotruk self-develop HW brand, derived from Fuller gearbox, manual operation (MT), 10/12 forwards and 2 reverses, synchronizer is optional as well.
10. Rear Axle: double stage reduction, with full range of diff. ratio, suitable for all complex and mixed road condition.
11. Right Hand Drive, Left Hand Drive, Colors are optional.
12. Tyres: Tube or tubeless is optional. Mining purpose tyres can be equipped. China famous tyre brand, TRIANGE, is mostly used.
