SINOTRUK HOWO 4X2 light rear compression garbage truck is a compact and efficient waste management vehicle designed for urban and residential areas where maneuverability and versatility are essential. Built on a SINOTRUK lightweight chassis, the garbage compactor can be made 6cbm to 10cbm. This truck is ideal for collecting and compressing waste in narrow streets, small communities, and areas with limited space, and widely used in Africa, Southeast Asia, South America, and Middle East.
Specification
SINOTRUK HOWO 4X2 LIGHT REAR COMPRESSION GARBAGE TRUCK | |
Model | ZZ1047D3815C145 |
Cabin | 1880/2880 Option: without sleeper or one sleeper, with or without A/C |
Engine | YUNNEI brand, 110HP, 116HP, Euro II Emission standard YUCHI brand, 140HP, 160HP, Euro II Emission standard |
Transmission | WLY, manual, 6 F & 1 R HW90510C, manual, 10 F & 2 R |
Front axle | 2000kg-3600kg loading capacity |
Rear axle | 3500kg-10500kg loading capacity |
Steering | LHD or RHD, with Hydraulic assistance |
Tire | 7.00R16, 7 pcs (including one spare tire) Option: 7.50R16, 8.25R16, 8.25R20, 9.00R20, 10.00R20 |
Fuel tank | 120L, 150L, 220L |
Garbage Container | 8 CBM Optional: 6CBM, 10CBM |
Hydraulic system control method | Electronic control + Manual control |
Overall dimension | 7500*2400*3000 mm |
Color | White, Red, Blue ,Yellow, Gray |
Product Features
1. All compression garbage trucks are equipped with high tensile steel leaf springs suspension and reinforced double-layer chassis.
2. Classic engine: YUNNEI engine, YUCHAI engine, COMMINS engine, 110hp, 116hp, 140hp, 154hp, 160hp, and 168hp for option;
3. Transmission: Sinotruk self-develop HW brand, 10 forwards and 2 reverses. And China famous brand WLY is optional as well.
4. Right Hand Drive, Left Hand Drive, Colors are optional.
5. Tyres: Radial tyres, Tube or tubeless is optional.
6. Compactor Capacity: Designed to carry a significant volume of waste, improving operational efficiency. 6cbm to 10cbm is optional.
7. Durable Body: Made from high-strength steel to withstand harsh working conditions and resist corrosion.
8. Optimized manual and electro hydraulic control system helps to avoid operation errors, it has higher safety and operation efficiency.
9. Hydraulic System: The garbage truck is equipped with a hydraulic system that facilitates easy lifting and dumping of waste into the garbage box.
10. Efficient Compression System: Equipped with a high-performance compression mechanism to maximize waste capacity and reduce transport frequency.
11. Eco-friendly: The compression system improves garbage collection and transportation efficiency, reducing the number of trips required to transport waste to landfill sites. This feature results in lower fuel emissions and a smaller carbon footprint.
12. Low Maintenance: Designed for easy maintenance with accessible components and durable materials.
