Widely employed in the transportation of construction waste and ores, the SINOTRUK HOWO NX 6X4 10-wheel tri-axle diesel dump truck stands out for its solid build, high load-bearing capability, and low fuel consumption. It is commonly used in regions such as Africa, Central Asia, Southeast Asia, and South America. The cargo box of this truck has a volume spanning 15CBM to 25CBM and can bear a maximum load of 40 tons. We also provide tailored solutions for the cargo box, allowing for modifications to its size and steel plate thickness as per customer requirements.
Product Features
1. All dump trucks are equipped with high tensile steel leaf springs suspension and reinforced double-layer chassis.
2. Plenty of options are available, including driver's air seat ensuring driver's comfortable driving experience, engine oil pan and intercooler protection plate, top mounted alarming beams (single and dual), engine exhaust valve brake (EVB), oil bath air inlet system good for dusty working condition to protect engine from inhale impure air, reverse buzzer, wind deflector to reduce wind resistance.
3. Classic engine: 380hp, 400hp and 430hp for option ; with Euro ll, Ill, IV, V, VI emision standard;
4:Gearbox/Transmission: Sinotruk self-develop HW brand, derived from Fuller gearbox, manual operation (MT), 10/12 forwards and 2 reverses, synchronizer is optional as well.
5. For some market where the weather temperature is very high, water dripping system is optional for cooling brake drum.
6. Rear Axle: double stage reduction, with full range of diff. ratio, suitable for all complex and mixed road condition.
7. Right Hand Drive Left Hand Drive Colors are optional.
8. Tipping hydraulic system: front posed vertical lifting mechanism and middle lifting mechanism. HYVA brand is optional.
9. Tipping Cargo Body: Customized according to different purposes, thickness of side walls can be thickened and thinned, reinforced; anti-abrasive material steel, high tensile steel, HARDOX, manganese steel.
10. Tyres: Mining purpose tyres can be equipped. China famous tyre brand, TRIANGE, is mostly used
Specification:
SINOTRUK HOWO NX 6X4 Heavy Duty Dump TRUCK | |
Model | ZZ3257V384JB1 |
Cabin | H77L, long cabin, with air conditioner |
Engine | WP10.380E22, 380HP, Euro II Emission standard Option:WP10.400E201(400HP), WP12.430E201(430HP) |
Transmission | HW19710, manual, 10 F & 2 R |
Front axle | 9500kg loading capacity |
Rear axle | 2*16000kg loading capacity |
Steering | Bosch brand, with Hydraulic assistance |
Tire | 315/80R22.5, 11 pcs (including one spare tire) Option:12.00R20,13R22.5 |
Fuel tank | 300L/400L |
Cargo box | 5600*2300*1500mm, floor 8mm side plate 6mm, under body hydraulic lifting system.U shape cargo box with High strength steel plate, for example NM450,T700 and Hardox 450 etc |
Overall dimension | 8450*2550*3500 mm |
Color | Option |
