sinotruk howo 4x2 light fire truck（simple version）

Specification

Product Features

1. The chassis uses a dedicated SINOTRUK HOWO light truck chassis, offering strong load-bearing capacity and stable performance, compact and flexible, with strong maneuverability. The truck is compact in design and can be used in township fire stations.

2. The specialized section consists of a liquid tank, pump room, equipment compartment, power output and transmission system, pipeline system, electrical system, and other components.

3. The fire truck adopts a single-row integrated structure, providing a wide field of vision and accommodating more personnel, with a capacity of 2 people. The fire truck can perform firefighting operations while moving, with a long range and strong firefighting capabilities.

4. The fire pump model is Hale MBP imported brand, with a flow rate of 60L/S and a pressure of 1.00Mpa. The fire monitor model is PL24-28, with a shooting range of more than 60 meters.

5. The carriage is made of high-quality steel and high-strength aluminum alloy profiles, with both inner and outer skins constructed from corrugated aluminum sheets. The tank is designed with multiple anti-sloshing baffles.

6. The truck adopts the tank-mounted design, which provides enough installation space for the fire pump and gun. It adopts imported equipment and has a range of 60 meters, which can effectively meet the use of some special working conditions.

7. The roll-up doors of the equipment compartment are made of high-quality aluminum alloy, featuring flexible operation, low noise, good sealing, and an attractive appearance.

8. The pump room is equipped with a water pump system, various meters, indicator lights, liquid level gauges, pressure gauges, vacuum gauges, and other devices.

9. Foam tank and dry powder tank are optional according to usage requirements.
