SINOTRUK HOWO 6X4 Fire Truck

Fire Truck

Product Details

This truck has an excellent mobility. Its overall structure and layout are rational, with simple and convenient operation and maintenance. It supports electric, pneumatic, and manual operations, meeting the requirements of practical firefighting. It is suitable for use by public security fire brigades in large and medium-sized cities, as well as professional fire teams in petrochemical enterprises, ports, docks, and airports, for extinguishing large-scale oil fires and fires involving other materials.

Inquiry now Join Inquiry Car

PRODUCT DETAILS

Specification

SINOTRUK HOWO 6X4 16TON WATER/FOAM TANK FIRE TRUCK
Model	ZZ1257V4647B1
Cabin	HW76, one row with two seats or two rows cabin with 5-7 seats, with air condition
Engine	WP10.380E22, 380HP, Euro II Emission standard Option：WP10.340E22(340hp) WP12.400E201(400hp)
Transmission	HW19710, manual, 10 F & 2 R
Front axle	9000kg loading capacity
Rear axle	16000kg loading capacity
Steering	Bosch brand, with Hydraulic assistance
Tire	315/80R22.5, 11 pcs (including one spare tire) Option:12.00R20, 12R22.5
Fuel tank	400L
Pump	Model CB10/60, flow 3600 L/min
Fire monitor	Model PS60, imported brand as option
Monitor reach	Water≥70m Foam≥60m
Container Tank	Water(12T) and Foam(4T) or Water only(16T), and dry powder as option
Overall dimension	1040025503400 mm
Color	As option

Product Features

1. All fire trucks are equipped with high tensile steel leaf springs suspension and reinforced double-layer chassis.

2. Plenty of options are available, including driver's air seat ensuring driver's comfortable driving experience, engine oil pan and intercooler protection plate, top mounted alarming beams (single and dual), engine exhaust valve brake (EVB), oil bath air inlet system good for dusty working condition to protect engine from inhale impure air, reverse buzzer, wind deflector to reduce wind resistance.

3. Classic engine: 340hp,371hp,380hp and 400hp for option ; with Euro ll, Ill, IV, V, VI emision standard;

4:Gearbox/Transmission: Sinotruk self-develop HW brand, derived from Fuller gearbox, manual operation (MT), 10/12 forwards and 2 reverses, synchronizer is optional as well.

5. For some market where the weather temperature is very high, water dripping system is optional for cooling brake drum.

6. Rear Axle: double stage reduction, with full range of diff. ratio, suitable for all complex and mixed road condition.

7. Right Hand Drive Left Hand Drive Colors are optional.

8. The fire pump model is CB10/60, with a flow rate of 60L/S and a pressure of 1.00Mpa. The fire monitor model is PS60, with a shooting range of more than 60 meters.

9. The carriage is made of high-quality steel and high-strength aluminum alloy profiles, with both inner and outer skins constructed from corrugated aluminum sheets. The tank is designed with multiple anti-sloshing baffles.

10. The external frame of the equipment compartment is made of high-quality carbon steel plates, while the internal frame uses high-strength aluminum alloy profiles, designed with a hidden lap joint structure. The interior panels are made of patterned aluminum sheets, surface-treated with anodic oxidation for durability. The compartment is rationally arranged for easy access to equipment, and specially designed clamping devices ensure secure storage of equipment.

11. The roll-up doors of the equipment compartment are made of high-quality aluminum alloy, featuring flexible operation, low noise, good sealing, and an attractive appearance.

12. The pump room is equipped with a water pump system, various meters, indicator lights, liquid level gauges, pressure gauges, vacuum gauges, and other devices.
