sinotruk howo tx 6x4 fire truck

Specification

Product Features

1. All fire trucks are equipped with high tensile steel leaf springs suspension and reinforced double-layer chassis, with HOWO TX series comfortable cab and attractive appearance

2. Plenty of options are available, including driver's air seat ensuring driver's comfortable driving experience, engine oil pan and intercooler protection plate, top mounted alarming beams (single and dual), engine exhaust valve brake (EVB), oil bath air inlet system good for dusty working condition to protect engine from inhale impure air, reverse buzzer, wind deflector to reduce wind resistance.

3. Classic engine: 460hp,430hp,480hp for option ; with Euro ll, Ill, IV, V, VI emision standard;

4:Gearbox/Transmission: Sinotruk self-develop HW brand, derived from Fuller gearbox, manual operation (MT), 10/12 forwards and 2 reverses, synchronizer is optional as well.

5. For some market where the weather temperature is very high, water dripping system is optional for cooling brake drum.

6. Rear Axle: double stage reduction, with full range of diff. ratio, suitable for all complex and mixed road condition.

7. Right Hand Drive Left Hand Drive Colors are optional.

8. The fire pump model is CB10/80, with a flow rate of 80L/S and a pressure of 1.00Mpa. The fire monitor model is PL64, with a shooting range of more than 55 meters.

9. The carriage is made of high-quality steel and high-strength aluminum alloy profiles, with both inner and outer skins constructed from corrugated aluminum sheets. The tank is designed with multiple anti-sloshing baffles.

10. The external frame of the equipment compartment is made of high-quality carbon steel plates, while the internal frame uses high-strength aluminum alloy profiles, designed with a hidden lap joint structure. The interior panels are made of patterned aluminum sheets, surface-treated with anodic oxidation for durability. The compartment is rationally arranged for easy access to equipment, and specially designed clamping devices ensure secure storage of equipment.

11. The roll-up doors of the equipment compartment are made of high-quality aluminum alloy, featuring flexible operation, low noise, good sealing, and an attractive appearance.

12. The pump room is equipped with a water pump system, various meters, indicator lights, liquid level gauges, pressure gauges, vacuum gauges, and other devices.
