sinotruk howo 4x2 light fire truck

Specification

Product Features

1. The chassis uses a dedicated SINOTRUK HOWO light truck chassis, offering strong load-bearing capacity and stable performance, compact and flexible, with strong maneuverability.

2. The specialized section consists of a liquid tank, pump room, equipment compartment, power output and transmission system, pipeline system, electrical system, and other components.

3. The fire truck adopts a single-row integrated structure, providing a wide field of vision and accommodating more personnel, with a capacity of 2 people. The fire truck can perform firefighting operations while moving, with a long range and strong firefighting capabilities.

4. The fire pump model is CB10/60, with a flow rate of 60L/S and a pressure of 1.00Mpa. The fire monitor model is PS60, with a shooting range of more than 60 meters.

5. The carriage is made of high-quality steel and high-strength aluminum alloy profiles, with both inner and outer skins constructed from corrugated aluminum sheets. The tank is designed with multiple anti-sloshing baffles.

6. The external frame of the equipment compartment is made of high-quality carbon steel plates, while the internal frame uses high-strength aluminum alloy profiles, designed with a hidden lap joint structure. The interior panels are made of patterned aluminum sheets, surface-treated with anodic oxidation for durability. The compartment is rationally arranged for easy access to equipment, and specially designed clamping devices ensure secure storage of equipment.

7. The roll-up doors of the equipment compartment are made of high-quality aluminum alloy, featuring flexible operation, low noise, good sealing, and an attractive appearance.

8. The pump room is equipped with a water pump system, various meters, indicator lights, liquid level gauges, pressure gauges, vacuum gauges, and other devices.

9. Foam tank and dry powder tank are optional according to usage requirements.
