SINOTRUK HOWO 4X2 light insulated trucks are widely used in fresh food delivery, dairy product delivery, transportation of baked goods and pre made dishes, vaccine delivery, transportation of biological products and pharmaceuticals, as well as some temperature sensitive chemicals. Due to its sturdy structure, high load-bearing capacity, and low fuel consumption, it is widely used in Central and South Asia, Africa, Southeast Asia, and South America. The volume of the cargo box is 13CBM-35CBM. The maximum load-bearing capacity can reach 15 tons, and we can customize the size and steel plate thickness of the cargo box according to your requirements.
Specification
SINOTRUK HOWO 4X2 LIGHT INSLULATED VAN TRUCK | |
Model | ZZ1047D3414C145 |
Cabin | 1880mm, 2 seats, with air conditioner |
Engine | YN4102QBZL, 116HP, Euro III Emission standard Option:YC4E160-33,(160HP), YC4E140-33(140HP) |
Transmission | WLY6TS55C, manual, 6 F & 1 R |
Front axle | 2400kg loading capacity |
Rear axle | 4200kg loading capacity |
Steering | SINOTRUK brand |
Tire | 7.50R16, 7 pcs (including one spare tire) Option: 8.25R16, 8.25R20, 7.00R16 |
Fuel tank | 120L |
Cargo box | 4165*2300*2300mm, top 105mm, side 80mm |
Overall dimension | 6000*2450*3500mm |
Color | White, Yellow |
Product Features
1. The carriage is made of high-quality thermal insulation materials, such as polyurethane foam. This material has excellent insulation performance and can effectively block the transfer of heat, allowing the interior of the carriage to maintain a relatively stable temperature environment even when the external temperature changes.
2. The sealing design of the carriage is excellent, and the edges of the car doors and the gaps in the carriage have been specially treated to reduce the possibility of heat exchange through the gaps, ensuring the accuracy and stability of the temperature inside the carriage.
3. Engine Performance: Usually equipped with efficient engines that provide adequate power while still prioritizing fuel economy. Compliance with emissions standards depending on the market (Euro II III IV/V/VII options available).
4. All light insulated van trucks are equipped with high tensile steel leaf springs suspension and reinforced chassis.
5. Good durability: Key components of the vehicle, such as the engine, transmission, and axles, have undergone rigorous durability testing. The quality of the vehicle's components is reliable and can adapt to complex road conditions and long-term, high-intensity transportation work, reducing the frequency of fault repairs.
6. Gearbox/Transmission: WLY brand, derived from Fuller gearbox, manual operation (MT), 5/6 forwards and 1 reverses.
7. For some market where the weather temperature is very high, water dripping system is optional for cooling brake drum.
8. Multiple engine brands and horsepower options are available, including YUNNEI, YUCHAI and CUMMINS engines with 116 HP, 115 HP, 130 HP, 140 HP, 160 HP, and more.
9. Tyres: Vacuum tires and radial tires are available for selection. China famous tyre brand, is mostly used.
